Установкa Thermo King RD-II SR w/TK 3.76 Engine схема HARNESS CONDENSER – 241C9
Обновление от: 12/16/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-5439 | HARNESS - condenser | 1 | |
| 55-2332 | BANDWRAP (.75 dia, black) | A/R | ||
| 44-4303 | BANDWRAP (.75 dia, blue) | A/R | ||
| 2 | 44-9589 | RECEPTACLE - 2-pin | 3 | |
| 44-9597 | TERMINAL - pin (14-16 ga) | 6 | ||
| 44-9590 | WEDGE - 2-pin | 3 | ||
| 3 | 44-9544 | RECEPTACLE - 3-pin | 2 | |
| 44-9597 | TERMINAL - pin (14-16 ga) | 6 | ||
| 44-9545 | WEDGE - 3-pin | 2 | ||
| 4 | 41-2320 | RECEPTACLE - 18-pin | 1 | |
| 41-1951 | STRAIN RELIEF - connector (18 position) | 1 | ||
| 44-9928 | PIN (14-18 ga) | 12 | ||
| 5 | 41-438 | TERMINAL - fork (#6 blue, 14-16 ga) | 2 | |
| 6 | 44-2793 | TERMINAL - ring (1/4 yellow, 10-12 ga) | 4 | |
| 7 | 44-2792 | TERMINAL - ring (#10 yellow, 10-12 ga) | 3 | |
| 8 | 44-2789 | TERMINAL - ring (1/4 blue, 14-16 ga) | 1 | |
| 9 | 44-5066 | TERMINAL - fingrip (14-18 ga) | 1 | |
| 10 | 44-2791 | TERMINAL - ring (#10 blue, 14-16 ga) | 3 | |
| 11 | 651-246 | TERMINAL - ring (#8 blue, 14-16 ga) | 1 | |
| 12 | 44-2790 | TERMINAL - ring (5/16 blue, 14-16 ga) | 1 | |
| 13 | 44-9585 | PLUG - 2-pin | 1 | |
| 44-9597 | TERMINAL - pin (14-16 ga) | 2 | ||
| 44-9586 | WEDGE - 2-pin | 1 | ||
| 44-9602 | PIN - sealing | 3 |
