Установкa Thermo King RD-II SR w/TK 3.76 Engine схема INTAKE & EXHAUST GROUP (DRY FILTER) – 213A6
Обновление от: 5/31/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-5567 | BRACKET - air cleaner | 1 | |
| 55-2957 | SCREW - bracket | 3 | ||
| 55-2086 | FLATWASHER | 3 | ||
| 55-1800 | LOCKWASHER | 3 | ||
| 2 | 55-5921 | CLAMP - air cleaner | 1 | |
| 3 | 11-9068 | FILTER - air cleaner (dry) | 1 | |
| 11-9068 OEM | Фильтр воздушный в сборе, MD/TS-Series | 10 020 ₽ |
|
|
| 4 | 11-9059 | ELEMENT - air cleaner | 1 | |
|
US-11-9059 | Фильтр воздушный, MD/T-Series | 2 410 ₽ |
|
|
10-11-9059 | Фильтр воздушный, MD/T-Series | 740 ₽ |
|
| 5 | 11-9091 | CLIP - base | 2 | |
| 6 | 11-9092 | EJECTOR - dust | 1 | |
| 7 | 92-5565 | BRACKET - air cleaner/ 3-way valve | 1 | |
| 8 | 13-734 | HOSE - air cleaner (filter to engine) | 1 | |
| 9 | 13-733 | HOSE - air cleaner (panel to filter) | 1 | |
| 10 | 55-4979 | CLAMP - hose | 3 | |
| 11 | 33-930 | GROMMET - hose | 1 | |
| 12 | 92-5566 | PANEL - blockoff | 1 | |
| 55-1587 | SCREW - panel | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 13 | 55-6808 | CLAMP - hose | 1 | |
| 55-3027 | SCREW - clamp | 1 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-2990 | NUT | 1 | ||
| 14 | 13-821 | MUFFLER | 1 | |
| 55-6184 | STUD - muffler to manifold | 4 | ||
| 55-6183 | LOCKWASHER | 4 | ||
| 15 | 33-1907 | GASKET - muffler | 1 | |
|
10-33-1907 | Прокладка глушителя, Yanmar 388 / 395 | 1 070 ₽ |
|
| 11-6291 | TUBE - exhaust (EMEIA) | 1 | ||
| 16 | 11-6173 | TUBE - exhaust (TSA) | 1 | |
|
10-11-6173 | Труба выхлопная | 4 650 ₽ |
|
| 11-6291 | TUBE - exhaust (EMEIA) | 1 | ||
| 17 | 55-3364 | PLUG - pipe | 1 | |
| 18 | 92-5564 | BRACKET - air cleaner & coolant tank | 1 |
