Установкa Thermo King RD-I TCIA EMEIA схема SWITCHES & SENSORS – 91G1
Обновление от: 1/30/03
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 107-186 | CLUTCH - electric (see 84C8) | 1 | |
| 2 | NSS | BOX - control (see 91G2) | 1 | |
| 3 | 44-3018 | SWITCH - water temperature | 1 | |
|
10-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 5 830 ₽ |
|
| PP-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 2 200 ₽ |
|
|
| 4 | 44-5810 | GLOW PLUG (manifold heater) | 2 | |
|
10-44-5810 | Свеча накаливания, Yanmar 235, 353 | 7 700 ₽ |
|
| 5 | 44-5305 | SWITCH - hpco | 1 | |
|
10-44-5305 | Выключатель высокого давления (R12) | 3 950 ₽ |
|
| 44-7327 | CONNECTOR - tower (1-pin) | 1 | ||
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 2 | ||
| 44-5839 | TERMINAL - female (14-16 ga) | 2 | ||
| 6 | 44-5219 | CONNECTOR (part of main harness) | 1 | |
| 7 | 11-4984 | ADAPTER - switch | 1 | |
| 8 | 55-2273 | TEE | 1 | |
| 9 | 44-4774 | SWITCH - oil pressure | 1 | |
|
10-44-4774 | Выключатель давления масла | 5 530 ₽ |
|
| 10 | 66-2009 | VALVE - pilot solenoid | 1 | |
|
10-66-2009 | Управляющий клапан, KD/MD/TD/RD-II / SB-I/II/III | 18 500 ₽ |
|
| 44-3803 | COIL - valve (3/8 bore) | 1 | ||
| 41-1525 | COIL - valve (7/16 bore) | 1 | ||
|
10-41-1525 | Катушка соленоида, 12V 8W | 15 030 ₽ |
|
| 55-8786 | NUT - valve | 1 | ||
| 11 | 44-7001 | STRAP - ground | 1 | |
| 12 | 91-1662 | BRACKET - circuit breaker | 1 | |
| 13 | 44-7325 | SWITCH - micro (solenoid) | 1 | |
| 33-428 | GROMMET | 3 | ||
| 14 | 44-6215 | SOLENOID - throttle (see 81E10) | 1 | |
| 44-2756 | DIODE - solenoid | 1 | ||
|
10-44-2756 | Диод соленоида тяги | 1 920 ₽ |
|
| 15 | 44-5305 | SWITCH - hpco | 1 | |
|
|
10-44-5305 | Выключатель высокого давления (R12) | 3 950 ₽ |
|
| 16 | 55-460 | ELBOW - switch | 1 | |
| 17 | 44-8428 | HARNESS - main | 1 | |
| 44-5214 | SOCKET - switch panel | 1 | ||
| 44-5220 | COVER | 1 | ||
| 18 | 44-5837 | SEAL - cable (gray, 14-16 ga) | 2 | |
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 4 | ||
| 44-5836 | TERMINAL - male (14-16 ga) | 4 | ||
| 19 | NSS | BOX - control (see 91G5) | 1 | |
| 20 | Not Used | |||
| 21 | 44-6016 | SENSOR - rpm (optional) | 1 | |
|
10-44-6016 | Датчик оборотов двигателя, SB-I/II/III / MD-200/300 / TS-200/300 | 8 900 ₽ |
|
| PP-44-6016 | Датчик оборотов двигателя, SB-I/II/III / MD-200/300 / TS-200/300 | 4 310 ₽ |
|
|
| 99-8110 | BRACKET - sensor | 1 | ||
| 22 | 44-8296 | HARNESS - Cycle Sentry (optional) | 1 | |
| 23 | 44-6116 | THERMOSTAT - block temperature (65 F, see note) | 1 | |
| 44-6018 | THERMOSTAT - block temperature (30 F) | 1 | ||
| 30-44-6018 | Выключатель температурный | 15 030 ₽ |
|
|
| 55-2997 | SCREW - switch | 2 | ||
| 55-3014 | LOCKWASHER | 2 | ||
| 55-3013 | FLATWASHER | 2 | ||
| 24 | 41-2194 | ALTERNATOR (23 amp, model 8MR) | 1 | |
|
10-41-2194 | Генератор 23A, KD/MD/RD/TD-II / TS / SB-II/III | 19 720 ₽ |
|
| 25 | 104-517 | ALTERNATOR - induction | 1 | |
| 77-1167 | BEARING - motor | 2 | ||
| 99-9084 | NAMEPLATE - arrow | 1 | ||
| 99-9700 | NAMEPLATE - 380VAC 50 Hz 3 phase | 1 | ||
| 91-1628 | COVER - junction box | 1 | ||
| 33-1671 | GASKET - cover | 1 | ||
| 55-5257 | CONNECTOR - harness | 1 |
