Установкa Thermo King RAC 60 OIW схема COVER - TOP – 266E3
Обновление от: 8/27/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 09-7084 | COVER - TOP, assembly (to be ordered in RAL 7011 - iron grey) | 1 | ||
| 1 | 98-8042 | COVER - weld | 1 | |
| 2 | 92-6647 | LATCH | 3 | |
| 3 | 92-7253 | COVER - latch | 3 | |
| 4 | 92-2444 | HINGE | 2 | |
| 55-7172 | SCREW - hinge | 10 | ||
| 55-7170 | LOCKWASHER | 10 | ||
| 55-9837 | NUT - captive | 10 | ||
| 5 | 92-6648 | DIFUSOR | 1 | |
| 55-9837 | NUT - captive | 1 | ||
| 6 | 78-1638 | FAN (400/460V, 50/60Hz) | 1 | |
| 55-7372 | SCREW - fan | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 55-8893 | FLATWASHER | 4 | ||
| 55-2330 | BANDWRAP | 3 | ||
| 7 | 92-6649 | BRACKET - cover support | 1 | |
| 55-5130 | RIVET - bracket | 2 | ||
| 8 | 55-8137 | SCREW - ground | 1 | |
| 55-7085 | FLATWASHER | 2 | ||
| 55-7342 | LOCKWASHER | 1 | ||
| 55-7825 | NUT | 1 | ||
| 9 | 33-739 | GROMMET (0.50 id) | 1 | |
| 10 | 92-6651 | INSULATION | 1 | |
| 11 | 92-6652 | INSULATION | 1 | |
| 12 | 92-783 | LABEL - ground | 1 | |
| 13 | 99-4931 | NAMEPLATE - arrow | 1 | |
| 14 | 99-7834 | NAMEPLATE - Caution High Voltage | 1 | |
| 15 | 99-8506 | NAMEPLATE - Caution, Fan | 1 | |
| 16 | 99-8507 | NAMEPLATE - Caution, Fan | 1 | |
| 17 | 92-1307 | NAMEPLATE - IR (black letters) | 1 | |
| 18 | 91-7551 | NAMEPLATE - TK Logo | 1 | |
| 19 | 92-6650 | SUPPORT - cover | 1 |
