Установкa Thermo King RAC 4 STD схема BLOWER – 186G1
Обновление от: 10/3/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-3228 | HOUSING - blower | 1 | |
| 55-6994 | SCREW - housing to frame | 11 | ||
| 55-7170 | LOCKWASHER | 11 | ||
| 55-7075 | FLATWASHER | 11 | ||
| 2 | 78-1389 | BLOWER (24VDC) | 1 | |
| 55-7862 | SCREW - blower to housing | 4 | ||
| 55-7369 | LOCKWASHER | 4 | ||
| 55-7697 | FLATWASHER | 4 | ||
| 3 | 92-6067 | RING - inlet | 1 | |
| 4 | 92-3229 | BRACKET - blower | 1 | |
| 51-1449 | SCREW - self tapping (bracket to housing) | 6 | ||
| 55-6994 | SCREW - bracket to frame | 7 | ||
| 55-7170 | LOCKWASHER | 7 | ||
| 55-7075 | FLATWASHER | 12 | ||
| 55-7354 | NUT | 5 | ||
| 55-9553 | NUT - captive | 2 | ||
| 5 | 40-974 | KIT - sensor (graded) | 1 | |
|
40-974 OEM | Датчик температуры к-т, калиброванный | 25 620 ₽ |
|
|
10-40-974 | Датчик температуры к-т, калиброванный | 4 660 ₽ |
|
| 6 | 55-9992 | BUSHING - sensor | 1 | |
| 7 | 55-9998 | LOCKNUT | 1 |
