Установкa Thermo King R9-M2 схема CONDENSER & EVAPORATOR COIL MOUNTING – 201H7
Обновление от: 2/15/05
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2126 | COIL - evaporator, curbside | 1 | |
| 2 | 67-2127 | COIL - evaporator, roadside | 1 | |
| 3 | 33-4143 | INSULATION - evap coil, side | 2 | |
| 4 | 33-4144 | INSULATION - evap coil | 2 | |
| 5 | 33-4145 | INSULATION - evap coil | 2 | |
| 6 | 92-4860 | PLATE - coil spacer | 2 | |
| 55-2270 | RIVET - plate | 2 | ||
| 55-8711 | INSERT (1/4 -20) | 12 | ||
| 55-8752 | INSERT (10-32) | 2 | ||
| 7 | 98-7156 | COVER - bottom | 2 | |
| 55-3136 | RIVET - coil | 10 | ||
| 8 | 67-2128 | COIL - condenser, curbside | 1 | |
| 9 | 67-2129 | COIL - condenser, roadside | 1 | |
| 55-3305 | SCREW - mtg coil | 8 | ||
| 55-2959 | LOCKWASHER | 8 | ||
| 55-2958 | FLATWASHER | 8 | ||
| 55-8976 | INSERT | 8 | ||
| 10 | 33-4146 | INSULATION - coil | 4 | |
| 11 | 33-4147 | INSULATION - coil | 8 | |
| 12 | 99-6968 | STRIP - sealing (cut to 11.4 in) | A/R | |
| 13 | 33-4148 | INSULATION - coil | 4 |
