Установкa Thermo King R6-M1 схема HARNESS GROUP (KIT 818140) – 173C4
Обновление от: 9/14/05
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-4757 | HARNESS - compressor control | 1 | |
| 2 | 44-5838 | CONNECTOR - tower (2-pin) | 2 | |
| 3 | 44-7881 | CONNECTOR - tower (4-pin) | 1 | |
| 4 | 41-4758 | HARNESS - compressor | 1 | |
| 5 | 44-7884 | CONNECTOR - shroud (22-pin) | 1 | |
| 44-7811 | LOCK - secondary | 1 | ||
| 6 | 41-4759 | HARNESS - driver panel | 1 | |
| 7 | 41-1508 | SOCKET - special switch (8-pin) | 1 | |
| 41-1507 | CONNECTOR - inline (2 terminals) | 1 | ||
| 44-6381 | CONNECTOR (female, 1 terminal) | 2 | ||
| 8 | 41-661 | CONNECTOR (14 terminal) | 1 | |
| 9 | 44-8537 | CONNECTOR (16 socket amp) | 1 | |
| 44-8779 | CLAMP - strain relief | 1 | ||
| 10 | 45-1865 | PANEL - driver display (see 135E14) | 1 |
