Установкa Thermo King R5-M2, M3, M5-M8, M12, RH5-M1, M2, R5-HP M6 схема VALVE ASSEMBLY - SUCTION – 127D14
Обновление от: 5/4/95
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 66-7880 | VALVE - suction | 1 | ||
| 1 | 306-804 | VALVE - suction | 1 | |
| 306-322 | KIT - valve repair | 1 | ||
| 2 | 33-2648 | O-RING - brass cap | 1 | |
| 33-2649 | O-RING - steel cap | 1 | ||
| 3 | 66-7664 | CAP - valve (brass) | 1 | |
| 66-7665 | CAP - valve (steel) | 1 | ||
| 4 | 66-7881 | TUBE | 1 | |
| 5 | 55-7073 | ADAPTER | 1 | |
| 6 | 11-2886 | VALVE - pressure (see 119G12) | 1 | |
| 7 | 303-700 | GASKET - valve | 1 | |
| 8 | 55-4794 | SCREW - valve | 2 |
