Установкa Thermo King PRECEDENT S-600 схема AIR EXCHANGER (OPTIONAL) – 267F0
Обновление от: 4/1/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-2823 | SOLENOID - damper | 1 | |
|
10-44-2823 | Соленоид оборотов двигателя | 5 370 ₽ |
|
| 51-2197 | SCREW - solenoid | 4 | ||
| 2 | 93-812 | LINK - damper | 1 | |
| 51-2391 | SCREW - sholder | 2 | ||
| 55-7697 | FLATWASHER | 6 | ||
| 55-7864 | NUT | 2 | ||
| 3 | 93-813 | SPRING | 1 | |
| 51-2392 | SCREW - sholder | 1 | ||
| 55-7089 | FLATWASHER | 1 | ||
| 4 | 93-814 | DAMPER | 1 | |
| 5 | 41-9914 | MAGNET | 1 | |
| 55-2270 | RIVET - magnet | 2 | ||
| 6 | 93-815 | BRACKET - switch | 1 | |
| 7 | 93-851 | BEARING | 2 | |
| 51-2197 | SCREW - bearing | 4 | ||
| 8 | 42-1014 | HARNESS - air exchanger | 1 | |
| 9 | 93-819 | BRACKET - air exchanger | 1 | |
| 10 | 93-817 | SCREEN | 2 | |
| 55-7067 | SCREW - screen | 4 | ||
| 51-1610 | WASHER | 4 | ||
| 11 | 41-9915 | SWITCH | 1 | |
| 12 | 93-852 | TUBE ASSEMBLY | 1 | |
| 13 | 93-830 | HOSE - middle | 1 | |
| 14 | 93-831 | HOSE - end | 1 | |
| 15 | 93-818 | TUBE - connection | 2 | |
| 16 | 55-2331 | BANDWRAP | 4 |
