Установкa Thermo King PRECEDENT S-600 схема EVAPORATOR BULKHEAD (OPTIONAL) – 261H4
Обновление от: 11/29/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 201-3044 | BULKHEAD - white (qty of 1) | A/R | |
| 201-3045 | BULKHEAD - black (qty of 1) | A/R | ||
| 201-3048 | BULKHEAD - white (w/ screen, qty of 1) | A/R | ||
| 201-3053 | BULKHEAD - black (w/ screen, qty of 1) | A/R | ||
| 201-3056 | KIT - screen (return air) | A/R | ||
| 2 | 55-2348 | SCREW - side (3 in.) | 6 | |
| 3 | 55-9383 | SCREW - bottom (1.25 in.) | 5 | |
| 4 | 55-9428 | WASHER | 11 |
