Установкa Thermo King PRECEDENT S-600 схема GRILLE GROUP – 261D1
Обновление от: 4/21/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-9117 | GRILLE - roadside (black, inc hinges, item 2) | 1 | |
| 93-853 | GRILLE - roadside (chrome, inc hinges, item 2) | 1 | ||
| 2 | 93-292 | HINGE - grille | 2 | |
| 51-2199 | SCREW - hinge | 4 | ||
| 3 | 93-293 | HINGE - frame | 4 | |
| 4 | 93-294 | PIN - hinge | 4 | |
| 5 | 98-9171 | INSERT - grille mesh (roadside) | 1 | |
| 51-2199 | SCREW - insert | 13 | ||
| 6 | 98-9118 | GRILLE - curbside (black, inc hinges, item 2) | 1 | |
| 93-854 | GRILLE - curbside (chrome, inc hinges, item 2) | 1 | ||
| 7 | 98-9119 | INSERT - grille mesh (curbside) | 1 | |
| 51-2199 | SCREW - insert | 13 | ||
| 8 | 33-5063 | GASKET - door seal (25 ft, cut to length) | A/R | |
| 9 | 33-5129 | INSULATION - muffler | 1 | |
| 10 | 42-859 | LED (optional) | 3 | |
| 42-986 | HARNESS - LED (optional) | 1 | ||
| 41-3074 | HOLDER - fuse | 1 | ||
| 30-41-3074 | Гнездо предохранителя | 600 ₽ |
|
|
| 41-4551 | FUSE - 5 amp | 1 | ||
| 30-41-4551 | Предохранитель 32V 5А | 520 ₽ |
|
|
| 41-124 | TERMINAL - splice | 1 |
