Установкa Thermo King PRECEDENT S-600 схема REFRIGERATION EVAPORATOR – 261B2
Обновление от: 6/18/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2728 | HEAT EXCHANGER | 1 | |
| 2 | 92-6491 | CLAMP - heat exchanger | 2 | |
| 51-2200 | SCREW - clamp | 4 | ||
| 3 | 92-9655 | BRACKET - clamp (curbside) | 1 | |
| 4 | 92-9656 | BRACKET - clamp (roadside) | 1 | |
| 51-1183 | RIVET - bracket | 8 | ||
| 5 | 55-7600 | CLAMP - tube | 2 | |
| 51-2254 | SCREW - clamp | 1 | ||
| 55-7075 | FLATWASHER | 2 | ||
| 55-7008 | NUT | 2 | ||
| 6 | 51-2257 | CLAMP (1/8) | 1 | |
| 7 | 61-6283 | VALVE - expansion | 1 | |
| 8 | 66-4441 | SCREEN - expansion valve (outlet) | 1 | |
| 9 | 61-6062 | TUBE - joint to expansion valve | 1 | |
| 10 | 66-620 | TEE | 1 | |
| 11 | 61-6063 | TUBE - equalizer | 1 | |
| 12 | 92-9660 | BRACKET - valve | 1 | |
| 51-2202 | SCREW - bracket | 3 | ||
| 13 | 51-2378 | U-BOLT | 1 | |
| 55-2001 | FLATWASHER | 2 | ||
| 55-4560 | NUT | 2 | ||
| 14 | 67-2727 | COIL - evaporator (see 261B1) | 1 | |
| 15 | 67-2793 | PAN - defrost drain (inc drain pan, tubes & brackets) | 1 | |
| 16 | 61-6223 | SCREEN - filter | 1 | |
| 17 | 61-5975 | TUBE - defrost (joint to distributor) | 1 | |
| 18 | 92-9658 | BRACKET - defrost tube | 4 | |
| 51-1183 | RIVET - bracket | 8 |
