Установкa Thermo King PRECEDENT S-600 схема ENGINE TK488CR – 260E4
Обновление от: 9/11/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 101-382 | ENGINE - TK488CR | 1 | ||
| 1 | 42-537 | SENSOR - air temperature, ambient | 1 | |
| 2 | 42-543 | GLOW PLUG | 1 | |
| 3 | 42-532 | CONNECTOR - glow plug | 1 | |
| 4 | 13-1255 | INJECTOR & GASKET | 4 | |
| 33-4966 | GASKET - injector | 4 | ||
| 5 | 13-1266 | RETAINER - injector | 4 | |
| 6 | 13-1329 | PIPE - rail in | 1 | |
| 7 | 13-1310 | PIPE - injection | 1 | |
| 8 | 13-1315 | PIPE - injection | 1 | |
| 9 | 13-1316 | PIPE - injection | 1 | |
| 10 | 13-1317 | PIPE - injection | 1 | |
| 11 | 13-1318 | RETAINER - injection pipe | 4 | |
| 12 | 13-1256 | RAIL ASSY | 1 | |
| 13 | 13-1253 | VALVE - EGR | 1 | |
| 14 | 13-1252 | PUMP - fuel, HPCR | 1 | |
| 15 | 33-5171 | O-RING - fuel pump | 1 | |
| 16 | 13-1262 | PIPE - fuel return | 1 | |
| 17 | 13-1263 | PIPE - fuel return | 1 | |
| 18 | 42-542 | SWITCH - oil pressure | 1 | |
| 19 | 41-4470 | SWITCH - oil level | 1 | |
|
41-4470 OEM | Датчик уровня масла, резьбовой | 12 990 ₽ |
|
|
10-41-4470 | Датчик уровня масла, резьбовой | 4 830 ₽ |
|
| 20 | 13-1270 | DIPSTICK - oil | 1 | |
| 21 | 11-5091 | CAP - filler | 1 | |
| 11-5091 OEM | Крышка маслозаливной горловины, Yanmar 353 / 366 / 374 / 388 / 395 / 482 / 486 / 486V | 3 500 ₽ |
|
|
| 33-1954 | O-RING - cap, filler | 1 | ||
| 22 | 42-535 | SENSOR - cam | 1 | |
| 23 | 13-1260 | PIPE - fuel return | 1 | |
| 24 | 11-9959 | FILTER - oil (EMI 3000) | 1 | |
| 11-9961 | FILTER - oil (severe duty) | 1 | ||
| 25 | 11-9338 | VALVE - oil drain (1/4 turn) | 1 | |
|
10-11-9338 | Клапан | 4 680 ₽ |
|
| 26 | 13-1063 | VALVE - oil drain (ESOC) | 1 | |
| 27 | 13-1037 | CAP - oil drain | 1 | |
| 28 | 13-1660 | COUPLING - oil drain | 1 | |
| 29 | 204-1999 | TOOL - oil drain | 1 |
