Установкa Thermo King PRECEDENT C-600 схема OIL FILTER & PUMP GROUP (TK468V25) – 270A9
Обновление от: 6/13/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 13-357 | PIPE - oil | 1 | |
| 2 | 55-4644 | BOLT - eye | 1 | |
| 3 | 33-3833 | SEAL - washer (10) | 2 | |
| 4 | 55-5792 | NUT | 1 | |
| 5 | 51-606 | BOLT - eye | 1 | |
| 6 | 55-4622 | WASHER - sealing (8) | 2 | |
| 7 | 12-1012 | PUMP - fuel injection see 270B2) | 1 | |
| 8 | 33-2931 | GASKET - oil filter bracket | 1 | |
| 9 | 11-9959 | FILTER - oil (EMI 3000) | 1 | |
| 10 | 11-9447 | FITTING - oil inlet (ESOC) | 1 | |
| 11 | 41-7063 | SWITCH - oil pressure | 1 | |
| 10-41-7063 | Датчик давления масла, SB-XXX/SB-III | 3 280 ₽ |
|
|
| 12 | 13-1658 | BRACKET - oil filter | 1 |
