Установкa Thermo King PRECEDENT C-600 схема CONTROL BOX - BATTERY CHARGER C-600 – 267G7
Обновление от: 6/8/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-239 | COVER | 1 | |
| 51-2212 | SCREW - cover | 4 | ||
| 2 | 33-5006 | GROMMET | 1 | |
| 3 | 92-9664 | COVER - battery charger | 1 | |
| 51-2212 | SCREW - cover | 4 | ||
| 4 | 92-9663 | BOX - battery charger | 1 | |
| 51-2212 | SCREW - box | 4 | ||
| 5 | 93-240 | SHIELD - heat | 1 | |
| 51-2212 | SCREW - heat shield | 2 | ||
| 6 | 41-9900 | CHARGER - battery (30 amp) | 1 | |
| 55-7007 | NUT - charger | 4 | ||
| 51-2171 | WASHER - nylon | 4 | ||
| 55-8893 | FLATWASHER | 4 | ||
| 7 | 42-568 | CONDUIT - harness | 1 | |
| 8 | 51-2248 | FITTING conduit (elbow) | 1 | |
| 51-2250 | NUT - fitting | 1 | ||
| 51-2252 | WASHER - sealing | 1 | ||
| 33-4926 | O-RING | 2 | ||
| 9 | 93-283 | NAMEPLATE - Battery Charger | 1 |
