Установкa Thermo King PGM MAX & PGM-II MAX схема COMPRESSOR GROUP – 125F6
Обновление от: 8/17/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-474 | COMPRESSOR - D214 (until 12/31/92, see 92E12) | 1 | |
| 102-476 | COMPRESSOR - X214 (R12, R502, after 1/1/93, see 132F2) | 1 | ||
| 8102-477 | COMPRESSOR - X214 (new exchange, R134a & R404A, see 111E4) | 1 | ||
| 2 | 77-2127 | PULLEY - compressor (R12 & R134a) | 1 | |
| 77-2053 | PULLEY - compressor (R502, R404A) | 1 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 3 | 77-2537 | BUSHING | 1 | |
| 70-184 | KIT - screws & washers | 1 | ||
| 4 | 55-9024 | KEY | 1 | |
|
10-55-9024 | Шпонка коленвала, X418/426/430 | 590 ₽ |
|
| 10 | 41-3846 | SWITCH - hpco (R502, R404A) | 1 | |
| 44-7992 | SWITCH - hpco (R12) | 1 | ||
| 44-9137 | SWITCH - hpco (R134a) | 1 | ||
| 11 | 33-2805 | GASKET - discharge valve | 2 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 12 | 22-188 | VALVE - discharge | 1 | |
|
10-22-188 | Клапан, Discharge | 8 260 ₽ |
|
| 13 | 66-3015 | CAP - valve (brass, incl gasket) | 1 | |
| P-17-10806-10 | Крышка сервисного клапана, латунь, 05K/05G/06D | 3 000 ₽ |
|
|
|
10-66-3015 | Крышка сервисного клапана, латунь, X426/430/640 | 3 000 ₽ |
|
| 33-350 | GASKET - cap | 1 | ||
| 14 | 55-1983 | CAP - flare | 5 | |
| 15 | 55-308 | ELBOW | 1 | |
| 16 | 33-768 | GASKET - flare | 1 | |
| 18 | 55-5295 | SCREW - valve | 2 | |
| 55-896 | FLATWASHER | 2 | ||
| 19 | 11-5513 | VALVE - port | 1 | |
| 20 | 33-211 | GASKET - adapter | 1 | |
|
33-211 OEM | Прокладка компрессора | 1 720 ₽ |
|
|
30-33-211 | Прокладка | 510 ₽ |
|
| 21 | 22-646 | ADAPTER - suction valve (with 102-474) | 1 | |
| 22-1010 | ADAPTER - valve (with 102-583) | 1 | ||
| 66-8927 | ADAPTER - valve (after 3/97) | 1 | ||
| 22 | 55-190 | SCREW - adapter | 4 | |
| 23 | 55-308 | ELBOW | 1 | |
| 25 | 66-1916 | VALVE - suction | 1 | |
|
10-66-1916 | Клапан всасывающий (Suction) | 13 270 ₽ |
|
| 26 | 55-184 | TEE | 1 | |
| 27 | 55-8650 | SCREW - valve | 2 | |
| 55-895 | FLATWASHER | 2 | ||
| 28 | 204-972 | TOOL - keyway alignment | 1 |
