Установкa Thermo King NSD-II схема EVAPORATOR COVER GROUP (NSD-II 1004 M1) – 104C8
Обновление от: 7/21/95
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-4246 | COVER - curbside | 1 | |
| 2 | 98-4247 | COVER - roadside | 1 | |
| 91-3756 | NUTSTRIP - cover | 10 | ||
| 55-3044 | RIVET - nutstrip | 20 | ||
| 3 | 91-4188 | HINGE - cover | 10 | |
| 91-3756 | NUTSTRIP - hinge | 10 | ||
| 55-2991 | SCREW - hinge & cover | 40 | ||
| 55-2964 | LOCKWASHER | 20 | ||
| 55-2001 | FLATWASHER | 60 | ||
| 55-4560 | NUT | 20 | ||
| 4 | 98-4134 | SUPPORT - cover | 1 | |
| 55-3021 | SCREW - support | 16 | ||
| 55-1800 | LOCKWASHER | 16 | ||
| 55-2086 | FLATWASHER | 12 | ||
| 55-3028 | WASHER - sealing | 4 | ||
| 5 | 91-4202 | RELEASE - latch | 2 | |
| 6 | 91-4206 | CABLE - latch | 2 | |
| 7 | 91-4201 | BRACKET - latch | 6 | |
| 8 | 91-3759 | LATCH - cover | 4 | |
| 9 | 98-4245 | BASE - evaporator | 4 | |
| 10 | 91-3740 | TUBE - drain (evaporator) | 4 | |
| 55-1587 | SCREW - tube | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 11 | 12-419 | HOSE - drain (3/4 id x 25 ft, silicone) | A/R | |
| 55-1521 | CLAMP - hose (drain) | 8 | ||
| 12 | 55-7322 | TEE - swivel | 1 | |
| 13 | 11-7738 | HOSE - air (1/8 od) | A/R | |
| 14 | 55-7320 | FITTING - bulkhead | 2 | |
| 15 | 91-3741 | CYLINDER - air | 2 | |
| 55-3000 | SCREW - cylinder | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-4560 | NUT | 6 | ||
| 16 | 11-7660 | FILTER - air | 2 | |
| 17 | 91-3873 | DOOR - fresh air | 1 | |
| 55-2991 | SCREW - door | 14 | ||
| 55-3008 | WASHER - sealing | 14 | ||
| 55-2001 | FLATWASHER | 14 | ||
| 55-4560 | NUT | 14 | ||
| 99-4976 | STRIP - gasket (door, 1/8 x 1/2) | A/R | ||
| 99-8429 | STRIP - gasket (1/16 x 1/2) | A/R | ||
| 99-7336 | STRIP - neoprene (0.12 x 0.8 x 50 ft) | A/R | ||
| 18 | 91-3874 | LINK - arm | 2 | |
| 19 | 91-3875 | YOKE - linkage | 2 | |
| 20 | 55-7334 | SPACER | 2 | |
| 55-3027 | SCREW - spacer | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-4560 | NUT | 2 | ||
| 21 | 55-7335 | SPACER | 2 | |
| 55-3029 | SCREW - spacer | 2 | ||
| 55-2201 | FLATWASHER | 4 | ||
| 22 | 55-7336 | SPACER | 2 | |
| 55-3027 | SCREW - spacer | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-4560 | NUT | 2 | ||
| 23 | 91-3768 | HOSE - drain | 4 | |
| 24 | 66-1273 | VALVE - check | 4 | |
| 25 | 99-9251 | STRIP - gasket | A/R | |
| 26 | 91-4207 | BRACKET - latch | 1 | |
| 27 | 55-538 | SCREW - cable | 4 | |
| 55-7467 | WASHER - special (w/ tab) | 4 | ||
| 55-4953 | NUT | 4 | ||
| 28 | 99-317 | SPRING - cable | 2 | |
|
10-99-317 | Пружина | 500 ₽ |
|
| 29 | 33-2369 | INSULATION (curbside) | 1 | |
| 30 | 33-2370 | INSULATION (roadside) | 1 | |
| 31 | 55-7319 | FITTING - air (1/4) | 1 | |
| 32 | 91-4651 | BRACKET - cable | 6 | |
| 33 | 91-4696 | INSULATION - handle | 4 |
