Установкa Thermo King NSD-I схема HOSE KIT (710512, R12) – 94G6
Обновление от: 12/16/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR - X426 C5 (subassembly, see 231A2) | 1 | |
| 2 | 33-544 | O-RING - suction (1-3/16 id x 1/16) | 4 | |
| 3 | 33-594 | O-RING - discharge (7/8 id x 1/16) | 4 | |
| 4 | 66-2998 | HOSE - refrigerant (1-1/8 id x 120) | 1 | |
| 5 | 66-2600 | HOSE - refrigerant (7/8 id x 120) | 1 | |
| 6 | 55-4366 | FITTING - swivel (1.5 od, straight) | 3 | |
| 7 | 55-4367 | FITTING - swivel (1.5 od, elbow) | 1 | |
| 8 | 55-4368 | ADAPTER - suction tube (1-5/8-12 thd x 1-1/8 sld) | 2 | |
| 9 | 55-3807 | FITTING - swivel/straight (1.0 od) | 3 | |
| 10 | 55-3809 | FITTING - swivel (1.0 od, elbow) | 1 | |
| 11 | 55-3808 | ADAPTER - discharge tube (1-15/16-12 thd x 1-1/8 sld) | 2 |
