Установкa Thermo King Modular Front Box II (901306) схема AIR INLET MODULE - AIR DUCT (008741) – 245B5
Обновление от: 8/30/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8396 | HOOD - air inlet | 1 | |
| 2 | 92-8081 | ENDSTOP | 1 | |
| 51-256 | RIVET - hood & endstop | A/R | ||
| 3 | 33-4537 | STRIP - sealing | A/R | |
| 4 | 92-8033 | BOX - filter | 2 | |
| 5 | 51-258 | SCREW - box | 4 | |
| 6 | 55-8375 | NUT - captive | 4 | |
| 7 | 92-8599 | FILTER - air inlet | 2 |
