Установкa Thermo King MRT-III Split схема COMPRESSOR GROUP (KIT 720190 & 720191) – 190A0
Обновление от: 9/9/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-668 | COMPRESSOR TM16 (24 V, poly groove 8V clutch, Kit 720190) | 2 | |
| 18-10158-04 OEM | Компрессор, TM-16, 24V 8PV, R134A/R404A | 22 740 ₽ |
|
|
|
10-TM-16-8-24 | Компрессор, TM-16, 24V 8PV, R134A/R404A | 22 740 ₽ |
|
| 102-815 | COMPRESSOR TM21 (24 V, 8K groove, Kit 720191) | 2 | ||
|
10-TM-21-8-24 | Компрессор TM-21, 24V 8PK | 28 910 ₽ |
|
| 22-1263 | FILTER - suction | 2 | ||
| 203-515 | OIL - compressor | A/R | ||
| 2 | 107-262 | CLUTCH (24 V, poly groove 8V, Kit 720190) | 2 | |
|
10-107-262 | Муфта электромагнитная, 8PV/24V, TM13/15/16, QP13/15/16 | 7 740 ₽ |
|
| 107-336 | CLUTCH (24 V, 8K groove, Kit 720191) | 2 | ||
| 3 | 41-594 | COIL (24 V, for connectors see 115D14) | 2 | |
|
10-41-594 | Катушка муфты сцепления, 24 V | 8 120 ₽ |
|
| 4 | 22-1121 | BRACKET - manifold | 2 | |
| 5 | 20-150 | KIT - manifold (straight, w/ o-ring fittings) | 2 | |
| 6 | 11-2886 | VALVE - assembly | 4 | |
| 55-7213 | VALVE - body | 4 | ||
| 11-7777 | CORE - valve | 4 | ||
| 55-5672 | VALVE - cap | 4 | ||
| 7 | 55-8537 | LOCKWASHER | 2 | |
| 8 | 55-8648 | SCREW | 2 | |
| 9 | 55-3364 | PLUG | 8 | |
| 10 | 91-7543 | NAMEPLATE - 24 VDC | 2 |
