Установкa Thermo King MRT-III N 1004 KAROSA схема CONTROL PANEL – 186A8
Обновление от: 7/22/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-9344 | FUSE (15 amp) | 5 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 2 | 41-1292 | FUSE (5 amp) | 1 | |
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 3 | 41-2978 | FUSE (20 amp) | 3 | |
| 30-41-2978 | Предохранитель 32V 20А | 500 ₽ |
|
|
| 4 | 41-1932 | FUSE (1 amp) | 1 | |
| 5 | 55-7367 | NUT | 1 | |
| 6 | 55-7034 | NUT - hexstop | 7 | |
| 7 | 99-3427 | MOUNT - cable tie | 2 | |
| 55-3010 | RIVET - mount | 2 | ||
| 8 | 41-896 | RELAY (1 pdt) | 12 | |
| 9 | 41-243 | STRAP - door | 1 | |
| 10 | 41-4157 | SENSOR - temperature | 1 | |
| 11 | 92-916 | PANEL - control | 1 | |
| 55-7373 | NUT - captive | 2 | ||
| 12 | 92-1464 | NAMEPLATE - fuse | 1 | |
| 13 | 41-4154 | BOARD - pc | 1 | |
| 14 | 55-7033 | FLATWASHER (M5) | 9 | |
| 15 | 55-7075 | FLATWASHER (M6) | 4 | |
| 16 | 55-7170 | LOCKWASHER | 4 | |
| 17 | 55-7169 | SCREW - strap | 1 | |
| 18 | 55-7172 | SCREW - panel | 4 | |
| 19 | 55-9706 | STUD - board | 8 | |
| 20 | 55-9624 | SPACER - board | 8 | |
| 21 | 51-310 | NUT (M5, plastic) | 1 |
