Установкa Thermo King MFB L схема BLOWER MODULE - SERVICE ACCESS (007095) – 215F1
Обновление от: 7/14/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-2534 | PROFILE - extruded | 2 | |
| 2 | 92-2523 | PROFILE - extruded | 2 | |
| 3 | 92-2563 | COVER | 1 | |
| 4 | 92-5801 | COVER - side | 1 | |
| 5 | 92-2546 | BRACKET - blind | 2 | |
| 51-258 | SCREW - side cover & bracket | 6 | ||
| 6 | 92-2564 | ANGLE | 2 | |
| 55-7169 | SCREW - angle | 4 | ||
| 51-130 | LOCKWASHER | 4 | ||
| 55-8375 | NUT - captive | 4 | ||
| 7 | 92-2567 | COVER - service | 1 | |
| 55-7340 | SCREW - cover | 2 | ||
| 51-130 | LOCKWASHER | 2 | ||
| 55-8375 | NUT - captive | 2 | ||
| 8 | 92-2565 | ANGLE - long | 2 | |
| 9 | 92-2566 | ANGLE - short | 2 | |
| 51-256 | RIVET - angle | 10 | ||
| 10 | 92-2528 | COVER - air outlet | 1 | |
| 11 | 92-2527 | ANGLE | 1 | |
| 12 | 92-5802 | ANGLE | 1 | |
| 13 | 92-2530 | BRACKET - Z profile | 1 | |
| 51-256 | RIVET - angle & bracket | 5 | ||
| 14 | 51-259 | HOLDER - blower | 2 | |
| 55-9481 | SCREW - holder | 4 | ||
| 55-9490 | WASHER | 4 | ||
| 55-8375 | NUT - captive | 4 | ||
| 15 | 33-3193 | STRIP - neoprene | A/R | |
| 16 | 99-2495 | STRIP - neoprene | A/R |
