Установкa Thermo King MET-HV-SP SLAVE Unit схема HEATER ASSEMBLY – 229H9
Обновление от: 5/22/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 45-2292 | HEATER | 1 | |
| 55-6994 | SCREW - heater | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-8893 | FLATWASHER | 8 | ||
| 55-9837 | NUT - captive | 8 | ||
| 2 | 41-4585 | SWITCH - temperature, 60 deg C | 1 | |
| 55-7829 | SCREW - switch | 2 | ||
| 55-7750 | LOCKWASHER | 2 | ||
| 3 | 41-8134 | BUSHING - cable | 1 | |
| 55-9560 | LOCKNUT | 1 | ||
| 4 | 55-6987 | SCREW - grounding | 1 | |
| 55-6988 | FLATWASHER | 2 | ||
| 55-6989 | LOCKWASHER | 1 | ||
| 51-1211 | NUT (jam) | 1 | ||
| 55-7825 | NUT | 1 | ||
| 5 | 92-7393 | INSULATION | 1 |
