Установкa Thermo King MD-200 MT схема ELECTRICAL COMPONENTS (S-2) – 197C2
Обновление от: 11/2/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-418 | SENSOR - temperature | 1 | |
| 44-9906 | TAB - connector | 1 | ||
| 2 | 61-2156 | SOLENOID - hot gas (see 116G14) | 1 | |
| 3 | 61-1037 | VALVE - solenoid (liquid) | 1 | |
| 60-276 | KIT - repair | 1 | ||
| 41-3681 | COIL | 1 | ||
| 41-3681 OEM | Катушка соленоида | 24 630 ₽ |
|
|
|
10-41-3681 | Катушка соленоида 12V | 12 220 ₽ |
|
| 4 | 61-1713 | SOLENOID - suction | 1 | |
| 5 | 41-6312 | HARNESS - sensor | 1 | |
| 6 | 78-1554 | BLOWER - variable (12V) | 2 | |
|
10-78-1362 | Вентилятор испарителя, Spectrum | 19 200 ₽ |
|
| 55-9694 | SCREW - blower | 8 | ||
| 7 | 78-1251 | HOUSING - blower | 1 | |
| 8 | 78-1252 | COVER - blower | 1 | |
| 9 | 92-4308 | BRACKET - terminal board | 1 | |
| 55-9693 | SCREW - bracket | 4 | ||
| 55-9763 | NUT | 4 | ||
| 10 | 44-6110 | BOARD - terminal | 1 | |
| 55-9694 | SCREW - terminal board | 4 | ||
| 11 | 92-4307 | MARKSTRIP - terminal board | 1 | |
| 12 | 41-4795 | WIRE - resistance (7327 mm) | 1 | |
| 13 | 41-4796 | WIRE - resistance (6267 mm) | 1 | |
| 14 | 44-3474 | SWITCH - air pressure | 1 | |
|
10-44-3474 | Переключатель воздуха | 7 150 ₽ |
|
| 55-4560 | NUT - switch | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 15 | 41-5178 | HARNESS - air switch | 1 | |
| 16 | 99-1143 | HOSE - air switch (black, 25 ft) | A/R | |
| 17 | 44-2915 | STRIP - jumper | 3 | |
| 91-9250 | NAMEPLATE - chassis | 1 | ||
| 18 | 41-1514 | SWITCH - defrost termination | 1 | |
|
10-41-1514 | Датчик окончания оттайки | 14 220 ₽ |
|
| 55-2260 | RIVET - switch | 2 | ||
| 19 | 41-5179 | HARNESS - air switch | 1 | |
| 20 | 91-7266 | CLAMP - sensor | 1 | |
| 55-9761 | SCREW - clamp | 1 | ||
| 21 | 41-2821 | HARNESS - evap fans (zone 1) | 1 | |
| 41-2823 | HARNESS - evap fans (zone 2) | 1 | ||
| 44-9688 | CONNECTOR - female (see171A4) | 2 |
