Установкa Thermo King MAN R02/R03 схема DAMPER GROUP – 181E1
Обновление от: 3/13/03
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-9142 | BEARING - plastic | 4 | |
| 2 | 92-685 | COUPLING - damper | 2 | |
| 3 | 41-3255 | SERVOMOTOR (24V, see grid 181E2) | 2 | |
| 4 | 55-7368 | FLATWASHER | 6 | |
| 5 | 55-7861 | LOCKWASHER | 6 | |
| 6 | 51-587 | SCREW - motor | 6 | |
| 7 | 92-2634 | BRACKET - damper (roadside) | 1 | |
| 8 | 92-2635 | BRACKET - damper (roadside, rear) | 1 | |
| 9 | 92-2636 | BRACKET - motor (roadside) | 1 | |
| 55-9866 | NUT - captive | 3 | ||
| 10 | 92-2637 | BRACKET - damper (curbside) | 1 | |
| 11 | 92-2638 | BRACKET - damper (curbside, rear) | 1 | |
| 12 | 92-2953 | BRACKET - motor (curbside) | 1 | |
| 55-9866 | NUT - captive | 3 | ||
| 13 | 92-2639 | DAMPER - fresh air | 2 | |
| 14 | 33-428 | GROMMET | 2 |
