Установкa Thermo King MAGNUM SL mP-4000 схема CONTROL BOX DOOR (mP-4000) – 259C6
Обновление от: 3/8/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-8723 | DOOR - front (mP-4000, includes keypad and VGA display) | 1 | |
| 2 | 33-4502 | GASKET - door | 1 | |
| 3 | 51-1844 | HINGE - top | 2 | |
| 51-1874 | SCREW | 6 | ||
| 4 | 92-7636 | BRACKET - connector | 1 | |
| 5 | 92-7637 | BRACKET - washer deutsch plug | 1 | |
| 51-1875 | RIVET (3 X 10 mm) | 4 | ||
| 51-1876 | RIVET (3 X 8 mm) | 1 | ||
| 6 | 92-7638 | BRACKET - cable | 1 | |
| 7 | 92-7559 | BRACKET - lock reinforcement | 1 | |
| 8 | 51-1843 | PIN - hinge | 2 | |
| 9 | 45-2295 | CONTROLLER (MP-4000) | 1 | |
| 10 | 41-8718 | MODULE - blanking | 2 | |
| 11 | 41-8717 | MODULE - battery | 1 | |
| 12 | 41-8724 | CABLE - retriever | 1 | |
| 13 | 41-2406 | CAP - dust | 1 | |
| 14 | 92-8690 | STRAP - cap | 1 | |
| 15 | 41-8716 | CABLE - serial (CM-4000 to PM-4000) | 1 | |
| 16 | 41-8715 | CABLE - serial (cargo) | 1 | |
| 17 | 41-9974 | CONNECTOR - 8-pin | 1 | |
| 41-9975 | CONNECTOR - 9-pin | 1 | ||
| 41-9976 | CONNECTOR - 4-pin | 1 | ||
| 41-9977 | CONNECTOR - 6-pin | 1 | ||
| 41-9978 | CONNECTOR - 17-pin | 1 | ||
| 18 | 42-353 | MODULE - AFAM+ | 1 |
