Установкa Thermo King MAGNUM SL mP-4000 схема USDA DOWNLOAD PANEL – 247C9
Обновление от: 12/31/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 42-308 | PANEL ASSEMBLY - USDA receptacle | 1 | ||
| 1 | 92-8692 | PANEL - USDA receptacle | 1 | |
| 2 | 41-2406 | CAP - dust | 1 | |
| 3 | 92-8690 | STRAP - cap | 5 | |
| 4 | 41-890 | CAP - dust | 4 | |
| 55-9323 | RIVET - cap | 4 | ||
| 5 | 41-2541 | RECEPTACLE (3-pin, Deutsch) | 4 | |
| 6 | 41-2405 | CONNECTOR - receptacle (5-pin, Deutsch) | 1 | |
| 55-2270 | RIVET - receptacle | 20 | ||
| 7 | 41-7183 | CABLE - NTC | 2 | |
| 8 | 41-9974 | CONNECTOR - plug (8-pin) | 1 | |
| 9 | 92-5392 | NAMEPLATE - data download USDA | 1 | |
| 10 | 41-8188 | SENSOR - thermistor (3-pin Deutsch, 14 m NTC, USDA) | 4 |
