Установкa Thermo King MAGNUM SL mP-4000 схема DEFROST DRAIN – 189C4
Обновление от: 9/8/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-5925 | GRILLE - condenser | 1 | |
| 51-1445 | SCREW - grille | 4 | ||
| 51-1464 | FLATWASHER | 4 | ||
| 55-9054 | WASHER (nylon) | 4 | ||
| 2 | 33-3043 | GASKET - grille (extrusion) | 1 | |
| 3 | 11-9734 | HOSE - drain (29 mm id, cut as required) | A/R | |
| 4 | 55-2330 | BANDWRAP | A/R | |
| 5 | 11-9735 | TEE - drain hose | 1 | |
| 6 | 11-9576 | HOSE - drain (21 mm id, cut as required) | A/R |
