Установкa Thermo King MAGNUM PLUS схема EVAPORATOR PANELS – 235G6
Обновление от: 9/22/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-5773 | PLATE - rear (bottom) | 1 | |
| 2 | 98-5772 | PLATE - rear (top) | 1 | |
| 51-336 | SCREW - plate | 23 | ||
| 55-9444 | WASHER - insulating | 23 | ||
| 55-3136 | RIVET - plate | 29 | ||
| 3 | 98-8244 | GRILLE - evaporator | 1 | |
| 55-3136 | RIVET - grille | 17 | ||
| 4 | 92-427 | CHANNEL - Z (100 mm deep) | 5 | |
| 51-621 | RIVET - channel | 39 | ||
| 5 | NSS | PANEL - USDA receptacle (see 235G4) | 1 | |
| 6 | 92-7639 | CHANNEL - air | 1 | |
| 55-9323 | RIVOT | 8 | ||
| 7 | 91-9330 | INLET - fresh air | 1 | |
| 55-9323 | RIVET - inlet | 10 | ||
| 8 | 92-7640 | CHANNEL - fresh air | 1 | |
| 55-9323 | RIVET - channel | 8 |
