Установкa Thermo King LRV-8T VR3 схема ELECTRICAL COMPONENTS – 253H7
Обновление от: 11/1/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-8933 | HARNESS - power outlet | 1 | |
| 2 | 41-8934 | HARNESS - power outlet heater | 1 | |
| 3 | 42-274 | WIRES - low voltage outlet | 1 | |
| 4 | 41-8935 | CABLE - temperature sensor (RAS) | 1 | |
| 5 | 41-8936 | CABLE - temperature sensor (FAS) | 1 | |
| 6 | 41-8937 | CABLE - temperature sensor (DAS) | 1 | |
| 7 | 41-8938 | HARNESS - low voltage heater | 1 | |
| 8 | 41-7513 | SENSOR - temperature | 2 | |
| 9 | 55-9554 | BUSHING | 2 | |
| 55-9558 | LOCKNUT | 2 |
