Установкa Thermo King LRV-8T VR3 схема UNIT MOUNTING – 253H1
Обновление от: 11/1/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-6371 | LIFTER - LRV | 1 | |
| 2 | 33-3422 | PAD - neoprene | 1 | |
| 3 | 51-840 | CLAMP | 6 | |
| 4 | 61-3599 | HOSE - silicone | 2 | |
| 5 | 61-3598 | TUBE - drain, assy | 2 | |
| 6 | 66-1273 | VALVE - check | 2 | |
| 7 | 92-856 | FILTER - air | 1 |
