Установкa Thermo King LRV-8T VR3 схема CONDENSER COVERS – 253G1
Обновление от: 11/1/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-6963 | COVER - condenser | 1 | |
| 2 | 98-6964 | COVER - condenser | 1 | |
| 3 | 98-6331 | COVER - centre | 1 | |
| 55-9368 | SCREW - covers | 32 | ||
| 51-871 | WASHER | 32 | ||
| 4 | 309-3224 | GRILLE - fan (outlet) | 2 | |
| 55-9368 | SCREW - grille | 12 | ||
| 55-8893 | FLATWASHER | 12 | ||
| 55-9553 | NUT - captive | 12 | ||
| 5 | 98-7717 | COVER - back | 1 | |
| 55-9368 | SCREW - covers | 12 | ||
| 51-871 | WASHER | 12 | ||
| 55-9553 | NUT - captive | 8 | ||
| 6 | 92-1955 | CLIP - cover back | 2 | |
| 55-7172 | SCREW - clip | 2 | ||
| 55-6996 | LOCKWASHER | 2 | ||
| 55-8893 | FLATWASHER | 2 | ||
| 7 | 55-7035 | SCREW - ground | 2 | |
| 55-7075 | FLATWASHER | 4 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 55-7354 | NUT | 2 | ||
| 8 | 92-783 | NAMEPLATE - ground | 2 | |
| 9 | 99-4931 | NAMEPLATE - arrow | 2 | |
| 10 | 92-3767 | LABEL - no step | 1 | |
| 11 | 92-2823 | LABEL - lifting | 2 | |
| 12 | 99-7834 | NAMEPLATE - caution, high voltage | 1 | |
| 13 | 92-1307 | NAMEPLATE - IR logo | 2 | |
| 14 | 99-8506 | CAUTION - fan | 1 | |
| 15 | 99-4976 | STRIP - neoprene | A/R | |
| 16 | 99-6968 | STRIP - neoprene | A/R |
