Установкa Thermo King LRV-12T TVS схема CONNECTOR KIT – 219B4
Обновление от: 2/12/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-7811 | CONNECTOR - assembly | 1 | |
| 41-5549 | HOUSING - connector | 1 | ||
| 41-5550 | FRAME - fixing | 1 | ||
| 41-5524 | COVER - connector, female | 2 | ||
| 41-5523 | COVER - connector, female | 2 | ||
| 41-7517 | INSERT - fixing | A/R | ||
| 2 | 51-699 | BUSHING - cable | 1 | |
| 41-696 | WASHER - sealing | 1 | ||
| 41-5552 | PIN - contact (female, 16 awg) | 13 | ||
| 41-5554 | PIN - contact (female, 10 awg) | 7 | ||
| 3 | 41-7812 | CONNECTOR - assembly | 1 | |
| 41-5549 | HOUSING - connector | 1 | ||
| 41-5550 | FRAME - fixing | 1 | ||
| 41-7144 | COVER - connector, female | 4 | ||
| 41-7517 | INSERT - fixing | A/R | ||
| 4 | 51-699 | BUSHING - cable | 1 | |
| 51-696 | WASHER - sealing | 1 | ||
| 41-5614 | PIN - contact (cdfa 1.5) | 21 | ||
| 41-5615 | PIN - contact (female, 0.75/1 mm sqr) | 10 | ||
| 41-7813 | PIN - contact (female, 16 awg) | 2 | ||
| 41-5616 | PIN - contact (female, 18 awg) | 3 | ||
| 5 | 41-7814 | CONNECTOR - assembly | 1 | |
| 41-5549 | HOUSING - connector | 1 | ||
| 41-5550 | FRAME - fixing | 1 | ||
| 41-5929 | COVER - connector, female | 4 | ||
| 41-7517 | INSERT - fixing | A/R | ||
| 6 | 51-699 | BUSHING - cable | 1 | |
| 51-696 | WASHER - sealing | 1 |
