Установкa Thermo King LRV-10T W1 схема FILTER UNIT – 254G9
Обновление от: 1/26/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8900 | FRAME - filter unit | 1 | |
| 55-6994 | SCREW - filter unit to HVAC unit | 17 | ||
| 51-871 | WASHER - sealing | 17 | ||
| 55-8893 | FLATWASHER | 17 | ||
| 2 | 98-6848 | ELIMINATOR - water | 1 | |
| 55-6994 | SCREW - water eliminator | 10 | ||
| 55-7170 | LOCKWASHER | 10 | ||
| 55-8893 | FLATWASHER | 10 | ||
| 55-9814 | NUT - captive, closed | 10 | ||
| 3 | 92-5206 | FRAME - filter | 1 | |
| 4 | 92-5207 | FILTER - air (master) | 1 | |
| 5 | 92-5208 | FILTER - air (master) | 1 | |
| 6 | 92-2820 | FILTER - air (aux) | 4 | |
| 7 | 98-6582 | ROOF - filter unit | 1 | |
| 8 | 55-2782 | SCREW - roof (quick turn captive) | 4 | |
| 9 | 55-7112 | WASHER - special | 4 | |
| 10 | 55-2074 | NUT - speed | 4 | |
| 55-3010 | RIVET - speed nut | 8 | ||
| 11 | 98-6583 | COVER - side | 2 | |
| 55-8837 | SCREW - cover | 8 | ||
| 51-871 | WASHER - sealing | 8 | ||
| 55-8835 | NUT - captive | 8 | ||
| 12 | 92-2821 | INSULATION | 1 | |
| 13 | 55-9992 | BUSHING - cable | 1 | |
| 51-355 | WASHER - sealing | 1 | ||
| 55-9998 | LOCKNUT | 1 | ||
| 14 | 92-3279 | RUBBER - profile | A/R | |
| 15 | 99-7336 | STRIP - neoprene | A/R | |
| 16 | 99-6968 | STRIP - neoprene | A/R | |
| 17 | 99-1908 | STRIP - neoprene | A/R | |
| 18 | 99-4931 | NAMEPLATE - arrow | 2 |
