Установкa Thermo King LRV-10T TTC схема FRAME & COVERS (FRONT BOX) – 218G6
Обновление от: 12/15/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-7759 | FRAME - front box | 1 | |
| 2 | 99-3281 | MOUNT - bandwrap | 8 | |
| 55-2330 | BANDWRAP | 8 | ||
| 55-5130 | RIVET - mount | 8 | ||
| 55-7664 | SCREW (M4) | 8 | ||
| 55-7697 | FLATWASHER | 8 | ||
| 55-9866 | NUT - captive (M4) | 8 | ||
| 51-190 | NUT - captive (M5) | 5 | ||
| 55-5130 | RIVET | 19 | ||
| 55-6994 | SCREW - front box to vehicle | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 3 | 98-7760 | COVER - front box | 1 | |
| 55-7407 | SCREW - cover (M5) | 6 | ||
| 51-1627 | WASHER - sealing | 6 | ||
| 4 | 92-6169 | INSULATION - cover | 1 | |
| 5 | 92-6170 | INSULATION - cover | 1 | |
| 6 | 92-6171 | INSULATION - cover | 2 | |
| 7 | 92-6172 | INSULATION - cover | 2 | |
| 8 | 92-6173 | INSULATION - bulkhead | 1 | |
| 9 | 92-6174 | GRILLE - filter | 1 | |
| 10 | 92-6175 | GRID - filter | 1 | |
| 11 | 92-6176 | FILTER | 1 |
