Установкa Thermo King LRV-10T TTC схема UNIT MOUNTING – 218G5
Обновление от: 12/15/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-6371 | LIFTER (LRV) | 1 | |
| 2 | 33-3422 | PAD - unit | 1 | |
| 3 | 33-3598 | PAD - unit | 1 | |
| 4 | 66-1273 | VALVE - check (drain hose) | 6 | |
| 5 | 55-2686 | CLAMP | 2 | |
| 6 | 51-840 | CLAMP | 6 | |
| 7 | 61-3949 | HOSE | 2 | |
| 8 | 61-3950 | TUBE - drain | 2 | |
| 9 | 55-9368 | SCREW | 2 | |
| 10 | 55-2782 | SCREW - fastener | 2 | |
| 11 | 55-6994 | SCREW | 2 | |
| 12 | 55-7075 | FLATWASHER | 2 | |
| 13 | 55-6996 | LOCKWASHER | 2 | |
| 14 | 55-2945 | WASHER | 5 |
