Установкa Thermo King LRT-SP M5 1004 (900273) схема UNIT GASKETS, DISPLAY, GRILLE & FILTER – 225F7
Обновление от: 11/20/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-4353 | GASKET - condenser, center | 1 | |
| 2 | 33-4412 | GASKET - condenser, side | 4 | |
| 3 | 33-4299 | GASKET - discharge (roadside) | 1 | |
| 4 | 33-4354 | GASKET - return air | 1 | |
| 5 | 33-4301 | GASKET - discharge (curbside) | 1 | |
| 6 | 51-192 | WASHER - spl | 12 | |
| 7 | 92-2763 | SPACER (1.50 in id) | 12 | |
| 8 | 92-1451 | PLUG - button, black | 12 | |
| 9 | 66-1273 | VALVE - drain | 4 | |
| 10 | 41-7215 | HARNESS - display | 1 | |
| 41-4284 | CONNECTOR (6 terminal, female) | 1 | ||
| 41-4285 | LOCK - terminal | 1 | ||
| 41-4283 | CONNECTOR | 1 | ||
| 41-4899 | WEDGE | 1 | ||
| 92-5199 | BRACKET - din panel | 1 | ||
| 11 | 41-7200 | MODULE - display, deluxe | 1 | |
| 55-2977 | SCREW - module | 4 | ||
| 55-3014 | LOCKWASHER | 4 | ||
| 55-3013 | FLATWASHER | 4 | ||
| 55-5754 | NUT | 4 | ||
| 12 | 98-7112 | FRAME - return air grille | 1 | |
| 13 | 91-8903 | HINGE - frame | 3 | |
| 55-2012 | RIVET - hinge | 9 | ||
| 14 | 98-7730 | DOOR - grille, return air | 1 | |
| 15 | 55-9283 | SCREW - lock | 3 | |
| 55-7112 | WASHER - spl | 3 | ||
| 16 | 55-2074 | NUT - speed | 3 | |
| 17 | 91-7625 | LOCKPLATE | 3 | |
| 55-2012 | RIVET - lockplate | 21 | ||
| 18 | 92-741 | FILTER - pad w/fabric) | 1 | |
| 19 | 92-4675 | BRACKET - filter | 2 | |
| 20 | 91-9343 | CLIP - filter | 1 |
