Установкa Thermo King LRT-SP (900751) схема UNIT GASKETS – 233G0
Обновление от: 4/1/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-4378 | GASKET - condenser, center | 2 | |
| 2 | 33-4412 | GASKET - condenser, side | 4 | |
| 3 | 33-4494 | GASKET - discharge (roadside) | 1 | |
| 4 | 33-4495 | GASKET - discharge (curbside) | 1 | |
| 5 | 92-2763 | SPACER (1.50 in dia) | 10 | |
| 6 | 51-192 | WASHER - spl | 12 | |
| 7 | 92-1451 | PLUG - button, black | 6 | |
| 8 | 33-4354 | GASKET - return air | 1 |
