Установкa Thermo King LRT-SP 5M (900379) схема INSTALLATION COMPONENTS – 221D5
Обновление от: 2/2/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 66-1273 | VALVE - hose check | 2 | |
| 2 | 203-391 | SEALER - tape | A/R | |
| 3 | 55-6726 | CLAMP - hose (0.50 - 1.12 dia) | 10 | |
| 4 | 33-3706 | STRIP - neoprene | A/R | |
| 5 | 91-186 | HOSE - drain (5/8 x 120) | 2 | |
| 92-3262 | HOSE - drain (5/8 x 12) | 2 | ||
| 6 | 98-7778 | HOSE - coolant (high temp) | 1 | |
| 7 | 33-1785 | O-RING (1-3/16 id) | 5 | |
| 33-1777 | O-RING (1-7/16 id) | 2 | ||
| 33-920 | O-RING (1-1/2 id) | 3 | ||
| 8 | 55-5740 | NUT - bulkhead (#16) | 1 | |
| 55-5741 | LOCKWASHER (1.5 id) | 1 | ||
| 55-5739 | NUT - bulkhead (#20) | 1 | ||
| 55-5996 | NUT - bulkhead (#24) | 1 | ||
| 55-5999 | LOCKWASHER (2.01 id) | 1 | ||
| 9 | 55-6349 | TEE - drain hose | 1 |
