Установкa Thermo King LRT-I 1000/1004 & LRT-II 1000/1004 схема HOSE KIT (099194, 715548) – 152C8
Обновление от: 4/6/99
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-633 | COMPRESSOR - TM31 (see 141F4) | 2 | |
| 2 | 41-2908 | HARNESS - compressor | 1 | |
| 3 | 66-8824 | HOSE - suction (16m) | 2 | |
| 4 | 66-8823 | HOSE - discharge (#12) | 2 | |
| 5 | 33-1777 | O-RING - suction (1-7/16 x 1/8 thk) | 2 | |
| 6 | 33-1785 | O-RING - discharge (1-3/16 x 1/8 thk) | 6 | |
| 7 | 55-5739 | NUT - suction (#20) | 2 | |
| 8 | 55-5740 | NUT - discharge (#16) | 2 | |
| 9 | 55-5742 | LOCKWASHER - suction (#20) | 2 | |
| 10 | 55-5741 | LOCKWASHER - discharge (16) | 2 | |
| 11 | 66-9569 | ADAPTER - suction (#20) | 2 | |
| 12 | 66-5247 | ADAPTER - bulkhead (#16, discharge) | 2 | |
| 13 | 91-1251 | BRACKET - fittings (o-ring seal) | 2 | |
| 14 | 55-5936 | NUT - shoulder | 4 | |
| 15 | 55-5938 | SLEEVE - adapter (#16) | 4 |
