Установкa Thermo King LRT-HP M6 1000 (900273) схема INSTALLATION COMPONENTS – 225G6
Обновление от: 8/17/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 51-2503 | FITTING - straight (o-ring seal, #12 hose x #10 fitting) | 1 | |
| 2 | 55-9414 | CAGE #12 | 2 | |
| 3 | 55-9418 | CLIP - hose #12 | 4 | |
| 4 | 67-1711 | HOSE (#12, 300 ft) | A/R | |
| 5 | 55-6838 | NUT - shoulder #8 | 1 | |
| 6 | 55-5740 | NUT - bulkhead adapter (#16) | 1 | |
| 7 | 55-7052 | SLEEVE - adapter (#12) | 1 | |
| 8 | 44-8708 | HOLDER - fuse | 1 | |
| 9 | 41-4576 | FUSE (150A, 32V) | 1 | |
| 10 | 78-1519 | BELT - Bx 81.0 | 1 |
