Установкa Thermo King LRC 35 TNN1 схема CONDENSER RIGHT – 234B7
Обновление от: 10/26/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2444 | COIL - condenser, right | 1 | |
| 55-6994 | SCREW - coil | 6 | ||
| 55-9190 | WASHER - spring | 6 | ||
| 55-8893 | FLATWASHER | 6 | ||
| 55-7373 | NUT - captive | 6 | ||
| 2 | 98-8193 | COVERING - assy | 1 | |
| 55-5130 | RIVET - covering | 10 | ||
| 3 | 99-7246 | STRIP - neoprene | A/R | |
| 4 | 92-3279 | RUBBER - profile | A/R |
