Установкa Thermo King LRC 35 MKII AUBAGNE схема ELECTRO BOX – 266C5
Обновление от: 5/16/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | ELECTRO BOX PANELS (see 266C6) | 1 | |
| 55-6994 | SCREW - box, side | 6 | ||
| 55-9190 | LOCKWASHER | 6 | ||
| 55-8893 | FLATWASHER | 6 | ||
| 55-7035 | SCREW - box, back | 3 | ||
| 51-871 | WASHER - sealing | 3 | ||
| 2 | NSS | SUBPANEL (see 266C7) | 1 | |
| 3 | NSS | TERMINALS (see 266C8) | 1 | |
| 4 | 45-2411 | CONTROLLER (24VDC, 35W) | 1 | |
| 51-1837 | SCREW - controller | 6 | ||
| 55-7369 | LOCKWASHER | 6 | ||
| 55-7697 | FLATWASHER | 6 | ||
| 5 | 93-338 | HOLDER - controller | 1 | |
| 6 | 93-337 | HOLDER - controller | 1 | |
| 55-9349 | SCREW - holder | 4 | ||
| 55-7369 | LOCKWASHER | 4 | ||
| 55-7697 | FLATWASHER | 4 | ||
| 7 | 51-1400 | BUSHING - cable | 1 | |
| 51-305 | LOCKNUT | 1 | ||
| 41-6682 | SEALING - bushing | 1 | ||
| 8 | 33-4490 | BUSHING - cable | 1 | |
| 55-9559 | LOCKNUT | 1 | ||
| 9 | 51-687 | BUSHING - cable | 1 | |
| 41-5619 | WASHER - sealing | 1 | ||
| 55-9711 | LOCKNUT | 1 | ||
| 10 | 41-8134 | BUSHING - cable | 3 | |
| 51-354 | WASHER - sealing | 3 | ||
| 55-9560 | LOCKNUT | 3 | ||
| 11 | 42-131 | ADAPTER | 1 | |
| 12 | 42-132 | NO CONTACT | 2 | |
| 13 | 42-134 | LAMP - led | 1 | |
| 14 | 42-133 | KNOB - rotary | 1 | |
| 15 | 42-135 | HOLDER - label | 1 | |
| 42-136 | LABEL - decal | 1 | ||
| 16 | 41-3928 | CONNECTOR | 1 | |
| 17 | 42-499 | CONNECTOR | 1 | |
| 18 | 42-500 | CONNECTOR | 1 | |
| 19 | 42-501 | CONNECTOR | 1 | |
| 20 | 42-1126 | CONNECTOR - ethernet | 1 | |
| 21 | 42-1127 | CRIMP - flange | 1 | |
| 22 | 42-1128 | CRIMP - ferrule | 1 |
