Установкa Thermo King LRC 35 MKII AUBAGNE схема FRAME - BOTTOM INSULATIONS – 266C1
Обновление от: 5/16/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-9174 | INSULATION | 1 | |
| 2 | 92-9175 | INSULATION | 1 | |
| 3 | 92-9178 | INSULATION | 2 | |
| 4 | 92-9177 | INSULATION | 1 | |
| 5 | 92-9176 | INSULATION | 1 | |
| 6 | 92-9180 | PLATE | 7 | |
| 7 | 92-9179 | PLATE | 2 | |
| 8 | 92-9181 | PLATE | 2 | |
| 55-3628 | RIVET - plates | A/R |
