Установкa Thermo King LRC 35 MKII AUBAGNE схема BLOWER – 253A6
Обновление от: 12/14/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 78-1808 | BLOWER | 1 | |
| 2 | 92-9185 | PLATE | 1 | |
| 55-7035 | SCREW - blower to plate | 10 | ||
| 55-9190 | WASHER - spring | 10 | ||
| 55-8893 | FLATWASHER | 10 | ||
| 3 | 92-9186 | PLATE - nut | 2 | |
| 4 | 92-9187 | SUPPORT | 1 | |
| 5 | 92-9188 | SUPPORT | 1 | |
| 55-7035 | SCREW - support (25 mm length) | 6 | ||
| 55-7752 | SCREW - support (12 mm length) | 4 | ||
| 55-9190 | WASHER - spring | 10 | ||
| 55-8893 | FLATWASHER | 10 | ||
| 51-290 | NUT - captive | 4 | ||
| 6 | 99-4931 | NAMEPLATE - arrow | 1 | |
| 7 | 99-6968 | STRIP - neoprene | A/R | |
| 8 | 41-7513 | SENSOR - temperature (service set - connector incl., see electrical components) | 1 | |
| 9 | 55-9554 | BUSHING | 1 |
