Установкa Thermo King LRC 35 MKII AUBAGNE схема LRC 35 MKII AUBAGNE REFERENCE SHEET – 19U22
Обновление от: 5/16/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 902415 | LRC 35kW AUBAGNE | 04/12 | ||
| 096775 | Kit - Circuit LRC 35 HA | 04/12 | ||
| 096773 | Kit - Condenser LRC MKII - 3 Condensers | 04/12 | ||
| 096900 | Kit - Frame LRC MKII 3 Condensers | 04/12 | ||
| 096686 | Kit - Condenser Fans LRC MKII | 04/12 | ||
| 096693 | Kit - Fresh Air LRC MKII | 04/12 | ||
| 096711 | Kit - Compressor LRC 35kW | 04/12 | ||
| 096696 | Kit - Heater LRC MKII 24kW | 04/12 | ||
| 096710 | Kit - Evaporator 35kW LRC MKII 5-Rows | 04/12 | ||
| 096687 | Kit - Blower LRC MKII | 04/12 | ||
| 096706 | Kit - Insulation BI | 04/12 | ||
| 096136 | Kit - Color LRV - White | 04/12 | ||
| 096868 | Kit - Cover LRC MKII | 04/12 | ||
| 096705 | Kit - Insulation TX | 04/12 | ||
| 096694 | Kit - Water Eliminator LRC MKII | 04/12 | ||
| 096878 | Kit - Electro LRC MKII AUBAGNE | 04/12 | ||
| 096605 | Kit - Fluids LRC 26 Basic | 04/12 |
