Установкa Thermo King LOCO PH37 схема SYSTEM CONNECTORS – 266D5
Обновление от: 6/26/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | CONNECTOR - XPOW1 | 1 | |
| 2 | 42-605 | HOUSING - connector | 1 | |
| 3 | 51-2623 | BUSHING | 1 | |
| 4 | 41-7517 | INSERT - fixing | 2 | |
| 5 | 42-591 | FRAME - fixing | 1 | |
| 6 | 41-5524 | COVER - connector, female | 2 | |
| 7 | 41-7144 | COVER - connector, female | 1 | |
| 8 | 41-7145 | PIN - connector, size 4mm | 3 | |
| 9 | 42-1184 | PIN - connector, size 1.5mm | 3 | |
| 10 | 41-7813 | PIN - connector, 16 awg, female | 10 | |
| 11 | 42-1185 | TERMINAL - wirepin, yellow | 1 | |
| 12 | 42-1186 | TERMINAL - wirepin, red | 1 | |
| 13 | NSS | CONNECTOR - XINV | 1 | |
| 14 | 42-1187 | HOUSING - connector | 1 | |
| 15 | 51-2624 | BUSHING | 1 | |
| 16 | 41-5504 | FRAME - fixing | 1 | |
| 17 | 41-5505 | COVER - connector, male | 1 | |
| 18 | 41-7516 | COVER - connector, male | 1 | |
| 19 | 41-5300 | COVER - connector, male | 2 | |
| 20 | 41-7517 | INSERT - fixing | 2 | |
| 21 | 41-5557 | PIN - connector, 16 AWG, male | 17 | |
| 22 | 41-9916 | PIN - connector, size 4mm, male | 3 | |
| 23 | 42-1188 | TERMINAL - wirepin, blue | 1 | |
| 24 | NSS | CONNECTOR - XLV1 | 1 | |
| 25 | 41-9840 | HOUSING - connector | 1 | |
| 26 | 51-2625 | BUSHING | 1 | |
| 27 | 41-7517 | INSERT - fixing | 2 | |
| 28 | 41-6745 | FRAME - fixing | 1 | |
| 29 | 41-5523 | COVER - connector, female | 1 | |
| 30 | 41-7144 | COVER - connector, female | 1 | |
| 31 | 41-7177 | PIN - contact, female | 8 | |
| 32 | 41-9036 | PIN - connector, size 5mm, female | 12 | |
| 33 | 42-1186 | TERMINAL - wirepin, red | 2 | |
| 34 | NSS | CONNECTOR - P2 | 1 | |
| 35 | 41-661 | CONNECTOR - in-line, 14 term | 1 | |
| 36 | 41-1807 | SOCKET - 10AMP 18-24GA | 9 | |
| 37 | NSS | CONNECTOR - P1 | 1 | |
| 38 | 41-650 | CONNECTOR - in-line, 18 term | 1 | |
| 39 | 41-1807 | SOCKET - 10AMP 18-24GA | 11 |
