Установкa Thermo King LOCO PH37 схема HEATER – 266A7
Обновление от: 4/23/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 45-2543 | HEATER | 1 | |
| 55-6994 | SCREW - heater | 5 | ||
| 55-9190 | LOCKWASHER | 5 | ||
| 55-8893 | FLATWASHER | 5 | ||
| 2 | 42-1092 | SWITCH - thermostat with manual reset 130 deg C | 1 | |
| 3 | 41-5937 | SWITCH - temperature, 70 deg C | 1 | |
| 55-7829 | SCREW - switch | 4 | ||
| 55-7750 | LOCKWASHER | 4 | ||
| 4 | 93-1013 | INSULATION | 1 | |
| 5 | 93-1014 | INSULATION | 1 |
