Установкa Thermo King LOCO PH37 схема REFRIGERATION CIRCUIT – 266A2
Обновление от: 4/23/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-6486 | TUBE | 1 | |
| 2 | 67-2358 | TANK - receiver | 1 | |
| 3 | 55-4979 | CLAMP | 1 | |
| 4 | 61-6487 | TUBE | 1 | |
| 5 | 61-381 | FILTER - drier (dehydrator) | 1 | |
| 6 | 61-6488 | TUBE | 1 | |
| 7 | 61-6489 | TUBE | 1 | |
| 8 | 66-9558 | VALVE - solenoid | 1 | |
| 51-902 | SCREW - valve | 1 | ||
| 51-1539 | FLATWASHER | 2 | ||
| 51-1451 | WASHER - spring | 1 | ||
| 55-7698 | NUT | 1 | ||
| 9 | 61-6490 | TUBE | 1 | |
| 10 | 66-9842 | VALVE | 3 | |
| 11 | 61-6491 | TUBE | 1 | |
| 12 | 41-4147 | SWITCH - low pressure cutout (connector incl.) | 1 | |
| 13 | 61-391 | ELIMINATOR - vibration (id 22.2) | 1 | |
| 14 | 61-6492 | TUBE | 1 | |
| 15 | 61-6493 | TUBE | 1 | |
| 16 | 61-6494 | TUBE | 1 | |
| 17 | 66-7392 | VALVE - relief, complete | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 18 | 33-1015 | O-RING | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 19 | 61-378 | ELIMINATOR - vibration (id 15.9) | 1 | |
| 20 | 61-6495 | TUBE | 1 | |
| 21 | 41-2588 | SWITCH - high pressure cutout (connector not incl.) | 1 | |
| 22 | 91-758 | CLAMP - switch | 2 | |
| 55-8316 | SCREW - clamp | 2 | ||
| 23 | 55-6388 | CLAMP - tube | 2 | |
| 55-8464 | SCREW - clamp | 2 | ||
| 55-9190 | LOCKWASHER | 4 | ||
| 55-8893 | FLATWASHER | 4 | ||
| 24 | 91-2487 | CLAMP - tube | 2 | |
| 305-1652 | SCREW - clamp | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 55-6995 | FLATWASHER | 2 |
