Установкa Thermo King LOCO KZT схема CONDENSER – 263D2
Обновление от: 10/22/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2799 | CONDENSER - right | 1 | |
| 2 | 67-2800 | CONDENSER - left | 1 | |
| 55-6994 | SCREW - condenser | 8 | ||
| 55-7170 | LOCKWASHER | 8 | ||
| 51-167 | FLATWASHER | 8 | ||
| 55-7373 | NUT - captive | 4 | ||
| 3 | 61-6324 | TUBE | 1 | |
| 4 | 61-6325 | TUBE | 1 | |
| 5 | 61-6326 | TUBE | 1 | |
| 6 | 61-6327 | TUBE | 1 | |
| 7 | 55-3441 | ELBOW | 2 | |
| 8 | 55-2187 | ELBOW | 2 | |
| 9 | 55-904 | TEE (5/8C x 5/8C x 5/8C) | 2 | |
| 10 | 91-758 | CLAMP - tube | 4 | |
| 55-8316 | SCREW - clamp | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 51-167 | FLATWASHER | 4 | ||
| 55-7373 | NUT - captive | 4 | ||
| 11 | 93-502 | INSULATION | 4 |
